Product Description

Features:

• Large High Scale RC Model
• Radio Controlled 2.4GHz 8 Channel Twin EDF Jet (Aileron, Elevator, Rudders, Throttle, Canard, Retracts With Doors, Drag Parachute Function, 360 Degree Thrust Vectoring Nozzles)
• Equipped with two RC controlling electronic 360 degree vector nozzles, makes the fighter more sensitive and could be controlled under gravity-free condition.
• It can complete every real action of the jet such as hanging, spin, flat spin and all other tricks.
• Stable invert flight; excellent stability of nosing up and down
• Working LED lights, suitable for night flight
• Working drag parachute function
• EPS foam material, High simulation. Unique design, fine making in details
• High speed (could be 120km/h) depends on the accessories.
• 2.4GHz spectrum remote transceiver available, with the functions of automatic identification and precise code pairing, strong anti-jamming, and allow more than 20 aircrafts to fly at the same field at same time
• Electronically retractable landing gear with suspension and cover doors

Specification:

Product Name:	SU47 Berkut
Length:	1500mm
Wingspan:	1125mm
Material:	EPS Foam
EDF Diameter:	70mm
Flying Weight:	2050g
Wing Area:	48d m2
Drive System:	2x Outrunner Brushless motors
Thrust:	2500g
Radio:	8 Channel
Servo:	16x 9g high speed micro servos
Speed Controller:	2x 50A Brushless speed controller
Thrust Vectoring:	Dual 360 degree thrust vectoring nozzles
Control System:	2.4GHz Multifunctional Transmitter and Receiver
Aircraft Battery:	Li-Po 22.2v/4000mAh (25C)



Product Info:

This Aircraft is NOT A TOY. It is not suitable for children under 14 years of age. Children under the age of 14 must not operate this product alone.  They must be accompanied by an experience adult at all times.



Flying Skill Level:

Advanced and experienced pilots recommended.

Build Level:

Moderate airplane assembly required. Internal wiring and electronics configuration is required. Please dry fit and test all electronics before gluing and securing any components.

Maintenance Level:

After every 5 flights and before and after storing airplane, please check all control surface horns and tighten the screws on surface horns if needed. Check the control pushrod clevis to insure no cracks are visible and no clevis has come loose. Check all control surfaces for solid contact between control surfaces, main wings and tail sections. Check for any loose screws anywhere screws are located. Check all wires connecting to the receiver for solid connection.

Please Note: If you have very little knowledge of Model Plane Assemble or have no Radio Control Flying experience, we would NOT recommend you to purchase this product to learn on.



Package Includes:

There is no clear industry standard definition for RTF, ARF, RXR, KIT, etc. Every manufacturer makes up their own definitions. The generally accepted definitions are: KIT means that you get all of the components of the plane, i.e.: fuselage, wings, tail, landing gear, even ducted fan, etc., pre-built but not pre-assembled; No electronic parts are included. RTF (Ready To Fly) means that you get the complete model, which includes all electronic parts—equipped model itself and RC Transmitter, Receiver, Flight Battery and 90 – 98% assembled. All “RTF” versions will have slight final assembly and setting up to do before flying. Required items: RC transmitter AA batteries and Li-po flight battery charger depending on the model aircraft purchased. RXR means that you get the RTF but no RC transmitter/Receiver. ARF means that you get the RTF but no RC transmitter/Receiver and no aircraft Battery.
